| MDR-60 60W Waterproof Irrigation Switch Power Supply | ||||
|---|---|---|---|---|
| Project | Technical Index | 12V Specs | 24V Specs | |
| Output | DC Voltage | 12V | 24V | |
| Rated Current | 5A | 2.5A | ||
| Rated Power | 60W | 60W | ||
| Ripple and Noise | < 120mV | < 150mV | ||
| Voltage Accuracy | ±1% | ±1% | ||
| Load Adjustment Rate | ±10% | ±10% | ||
| Linear Adjustment Rate | ±1% | ±1% | ||
| Starting and Rising Time | ±1% | ±1% | ||
| Input | Voltage Range / Frequency | 85-264VAC 47Hz—63Hz (120VDC—370VDC) | - | |
| Efficiency (typical) | > 86% | > 88% | ||
| Working Current | < 1.8A 110VAC / < 1A 220VAC | - | ||
| Impulse Current | 110VAC 35A / 220VAC 70A | - | ||
| Overload Protection | 500ms, 30ms, 25ms (110VAC) / 500ms, 30ms, 120ms (220VAC) | - | ||
| Protect | Overvoltage Protection | 105%-135% (Protection type: Hiccup mode, auto-recovery) | - | |
| Overload Recovery | >135% (Protection type: Close output, restart to recover) | - | ||
| Environment | Working Temperature & Humidity | -20°C ~ +70°C / 20% ~ 90% RH | - | |
| Storage Temperature & Humidity | -40°C ~ +85°C / 10% ~ 95% RH | - | ||
| Safety | Leakage Current | Input-Output: 0.5 KVAC for 1 minute | - | |
| Insulation Impedance | Input-Output, Input-Shell, Output-Shell: 500VDC / 100M Ω | - | ||
| Other | Size | 40 * 90 * 100 mm | - | |
| Net Weight / Gross Weight | 330g / 350g | - | ||
